Services

3D cutting of sections and closed profiles

We provide the service of cutting sections and closed profiles from carbon steel, stainless steel and aluminum, using the innovative STIGAL MultiProfiler 3D machine. The use of 3D plasma cutting technology makes it possible to:

cutting,
making holes,
chamfering,
scribing,
marking,
engraving.

The main advantage of this machine, apart from cutting, is the simultaneous execution of chamfer for welding, which eliminates scribing, manual flame cutting or grinding operations.

The machine has the following technical capabilities:

LENGTH (section / profile)	2500 mm – 15000 mm
FLATBARS dimension of section (min – max)	50x5 – 300x30
EQUAL LEG ANGLES dimension of section (min – max)	50x50x5 – 250x250x25
UNEQUAL LEG ANGLES dimension of section (min – max)	75x50x5 – 600x200
STEEL CHANNELS dimension of section (min – max)	C80 – C400
STEEL BEAMS dimension of section (min – max)	HEB 120 – HEB 600
CLOSED PROFILES dimension of section (min – max)	50x50 – 400x400
